Runva 11XP 24V with Synthetic Rope - IP67 Motor (RED)
Make 4 payments of $206.25 over 8 weeks and get it now!
Notify me when back in stock
Package includes:
- Winch with Dyneema Winch Rope
- Solenoid (24V/400A)
- Heavy Duty 1.8m Battery Leads
- Heavy Duty Leads from Solenoid to Winch Motor
- 3.7m Handheld Remote
- Wireless Remote
- Aluminium Hawse Fairlead
- Clevis Style Safety Hook
- Mounting Bolts
- Snatch Block
- Winch Cover
Features:
- Extremely watertight with heavy duty internal seals
- Free spooling clutch
- Full metal internal and external design
- 100% Waterproof competition grade Solenoids
- Winch power in and out via remote
- Heavy duty series wound motor
- Very compact full size winch
- Limited Lifetime Warranty
Specifications:
Rated Line Pull 11000lb (4990kg)
Motor - Series Wound (12V) 4.9kW/6.5HP
Gear Train Full Steel 3 Stage Planetary
Gear Ratio 230:1
Brake Automatic Load Holding Screw Cone
Dyneema 11mm x 26.5m
Steel Cable 9.2mm x 26.5m
Drum Size 63mm x 223m
Mounting Bolt Pattern 254mm x 114.3mm
Overall Dimensions 540mm x 163mm x 221mm
Remote Control 3.7m Handheld Remote/Wireless Remote
Battery Leads Included. 2 x 1.8m Heavy Duty Leads
Finish Red Powder Coat
Warranty Limited Lifetime
The perfect all-round winch. Attractive finish that would complement any vehicle no matter how tough or shiny.
| Line pull | Line speed ft/min (m/min) |
Current draw Amps (max) |
Layer of Cable | Rated line pull Per layer lb’s (kg) |
|
|---|---|---|---|---|---|
| lb | DC 12V | DC 12V | |||
| 0 | 22.3 (6.8) | 100 | 1 | 11000 (4990) | |
| 4000 | 13.1 (4.0) | 220 | 2 | 8766 (3976) | |
| 8000 | 9.8 (3.0) | 330 | 3 | 7286 (3305) | |
| 11000 | 5.8 (1.8) | 430 | 4 | 6233 (2827) |
(11XP-24VD-RED)
| SKU | 11XP-24VD-RED |
| Brand | Runva |
| Shipping Weight | 35.0000kg |
| Shipping Width | 30cm |
| Shipping Height | 30cm |
| Shipping Length | 40cm |
| Shipping Cubic | 0.036000000m3 |
General Warranty Information
Since all Runva Performance Winches are produced at the highest standard, we proudly offer a Limited Lifetime Warranty on all products.
Lifetime Mechanical Warranty This covers all Mechanical Components on the winch. (Except Steel Cable and Dyneema Winch Rope)
5 Year Electrical Warranty this covers all Electrical Components on the winch.
No Yearly Servicing Required
No Hidden Fine print
Extremely low failure rate.
In the unlikely event of a claim, they are acknowledged and handled very quickly
